| PARAMETER | SPECIFICATION |
| PRODUCTION SPEED | 90 – 100 pcs / min |
| DAILY OUTPUT | Up to 120,000 bags / day |
| BAG WIDTH | 100 – 500 mm |
| BAG HEIGHT | 180 – 450 mm |
| SIDE GUSSET WIDTH | 80 – 220 mm |
| MOLD CHANGE TIME | 90 seconds (fully automatic) |
| APPLICABLE MATERIAL | PP Nonwoven (Laminated & Non-laminated), RPET |
| MATERIAL WEIGHT | 30 – 120 GSM |
| HANDLE TYPE | Indirect Tape Applicator (Auto-centering) |
| VISION INSPECTION | AI Camera — Auto Defect Detection & Rejection (≤ 5‰) |
| DOWNSTREAM | Robotic Picking → Bundling → Case Erecting → Packing → Sealing → Palletizing |
| MACHINE SIZE & WEIGHT | 11,975 × 7,347 × 2,797 mm · 14,000 KGS |
| POWER SUPPLY | 380V / 50Hz / 3-Phase |
| CERTIFICATION | CE & ISO 9001 |
| WARRANTY | 1 Year from installation sign-off date |
-
